| 型號Model | ?D | R | A1 | RC | H | B | E | A2 | X | Y | X1 | C |
| PHF4-M5 | 4 | M5 | 3.5 | M5 | 8 | 16.7 | 20 | 4 | 11.8 | 10.5 | 10.4 | 15 |
| PHF4-01 | 4 | 1/8 | 7 | 1/8 | 14 | 29.2 | 22.4 | 7 | 11.8 | 10.5 | 10.4 | 15 |
| PHF4-02 | 4 | 1/4 | 9 | 1/4 | 17 | 33.8 | 25.5 | 10 | 11.8 | 10.5 | 10.4 | 15 |
| PHF6-M5 | 6 | M5 | 3.5 | M5 | 8 | 16.7 | 21.2 | 4 | 13.8 | 12.5 | 12.3 | 14.4 |
| PHF6-01 | 6 | 1/8 | 7 | 1/8 | 14 | 29.2 | 22 | 7 | 13.8 | 12.5 | 12.3 | 14.4 |
| PHF6-02 | 6 | 1/4 | 9 | 1/4 | 17 | 33.8 | 24.5 | 10 | 13.8 | 12.5 | 12.3 | 14.4 |
| PHF6-03 | 6 | 3/8 | 10 | 3/8 | 19 | 35 | 27.5 | 11 | 13.8 | 12.5 | 12.3 | 14.4 |
| PHF6-04 | 6 | 1/2 | 13 | 1/2 | 21 | 41.6 | 28.5 | 13 | 13.8 | 12.5 | 12.3 | 14.4 |
| PHF8-01 | 8 | 1/8 | 7 | 1/8 | 14 | 29.2 | 26.5 | 7 | 15.8 | 13.9 | 13.7 | 17.4 |
| PHF8-02 | 8 | 1/4 | 9 | 1/4 | 17 | 33.8 | 27 | 10 | 15.8 | 13.9 | 13.7 | 17.4 |
| PHF8-03 | 8 | 3/8 | 10 | 3/8 | 19 | 35 | 30 | 11 | 15.8 | 13.9 | 13.7 | 17.4 |
| PHF8-04 | 8 | 1/2 | 13 | 1/2 | 24 | 41.6 | 31.5 | 13 | 15.8 | 13.9 | 13.7 | 17.4 |
| PHF10-01 | 10 | 1/8 | 7 | 1/8 | 14 | 29.2 | 31 | 7 | 19.4 | 17 | 16.8 | 19 |
| PHF10-02 | 10 | 1/4 | 9 | 1/4 | 17 | 33.8 | 29.5 | 10 | 19.4 | 17 | 16.8 | 19 |
| PHF10-O3 | 10 | 3/8 | 10 | 3/8 | 19 | 35 | 30 | 11 | 19.4 | 17 | 16.8 | 19 |
| PHF10-O4 | 10 | 1/2 | 13 | 1/2 | 24 | 41.6 | 32 | 13 | 19.4 | 17 | 16.8 | 19 |
| PHF12-01 | 12 | 1/8 | 7 | 1/8 | 14 | 29.2 | 31 | 7 | 22.7 | 20.3 | 19.5 | 21.6 |
| PHF12-02 | 12 | 1/4 | 9 | 1/4 | 17 | 33.8 | 31 | 10 | 22.7 | 20.3 | 19.5 | 21.6 |
| PHF12-03 | 12 | 3/8 | 10 | 3/8 | 19 | 35 | 33.2 | 11 | 22.7 | 20.3 | 19.5 | 21.6 |
| PHF12-O4 | 12 | 1/2 | 13 | 1/2 | 24 | 41.6 | 36 | 13 | 22.7 | 20.3 | 19.5 | 21.6 |
